Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
18
4.2 SELECTION OF CLIP BANKS AND
PLAYLISTS
SHIFT + F1 - F9 = CLIPS BANK
This allows access to clip banks 1 through 9 within the clip page (1 to 10).
SHIFT + F1 = BANK 1
SHIFT + F2 = BANK 2, etc. (up to bank 9)
Once in the bank, selection of the F1 – F10 keys will call up the respective clips.
If Recall Clip Toggle is enabled in the Setup menu, pressing several times on the
same F_ key will call successively all camera angles of that clip.
The clip numbering system is as follows:
Example: Clip 547 where
• “5” refers to the clip page number (1 to 10).
• “4” refers to the clip bank (1 to 9)
• “7” refers to the clip number (1 to 10) inside the bank
SHIFT + F10 = playlist BANK
This combination of keys gives access to the playlists banks. Within each clip
page there are 10 playlists. Selecting F1-F10 at this point calls up the
corresponding playlist.
Example: Playlist 51 where:
• “5” refers to the clip page
• “1” refers to the playlist number (1 to 10)
Note
The playlist bank of page 10 is not available from the EVS remote, since
it is actually reserved for the EVS AVSP protocol.
