Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
14
4.1.11 BROWSE
When a clip is loaded on the primary channel, pressing the Browse key allows
the operator to browse inside all local clips of the database by turning the jog dial.
When a cue point exists for the current picture on the primary channel (the CUE
button lights red), pressing the Browse key allows the operator to browse through
all existing cue points by turning the jog dial.
When the current picture on the primary channel is neither a clip nor a cue point,
or if the operator is in Playlist mode, pressing the Browse key allows him to
browse inside the clips of the current playlist by turning the jog dial.
4.1.12 INSERT
This function inserts a clip before or after (depending on the Setup menu) the
current position inside the playlist.
4.1.13 ENTER
This function appends clip(s) at the end of the current playlist. This is also used to
confirm saving of clips, and validate various options and messages.
4.1.14 MENU
This function allows the operator to gain access to the secondary menu.
SHIFT + MENU on the Remote gains access to the Main menu.
Also used as an ESCAPE key to cancel some options and messages.
4.1.15 CLEAR
This function clears the IN / OUT/ playlist / CLIPS / CUE points.
Note
• To clear one CUE point, recall the desired cue point and press CLEAR
+ Mark keys.
• To clear all cues: when current picture is not a CUE point, press
CLEAR + Mark keys. A message appears to confirm the command.
4.1.16 NETWORK
This function is not accessible on XTnano.
