4.1.8 FAST JOG
When selected, this option enables fast picture search: the actual speed of this
fast jog is adjustable in the Setup menu. Starting a play or returning to E2E mode
resets the Fast Jog mode.
Important
The jog dial is active at all times when the system is in play and record.
The brake is automatically turned on when starting a playback with the
PLAY key or with the lever, or when returning to E2E mode with the
RECORD button.
4.1.9 LEVER
This function is used to perform slow-motion from 0 to 100%, and to playback
material from - 100 to + 100% or from - 200 to + 200% when Secondary Lever
range is selected. The lever has a continuous, linear range, except when Super
Motion material is loaded on the primary channel. In this case, there is a “flat
step” at 33% (SD Super Motion) or 50% (HD Super Motion) to help the operator
locating easily the ideal playback speed.
Important
When playing Super Motion material in slow motion, to obtain the
smoothest replay, it is important that the replay speed is exactly the ideal
slow motion speed, which is 33% for SD Super Motion or 50% for HD
Super Motion. If the replay speed is slightly off these ideal values,
movements might appear staggered. These ideal speeds can also be
called directly by pressing the PLAY button when the current element is
Super Motion. The PGM speed and Var Max modes can also be used to
facilitate this. See Chapter 6 ‘Pgm + Prv Mode’ on page 23 for a
de
scription on these modes.
4.1.10 PLST
This function is not active if the current playlist is empty. If the current playlist is
not empty, pressing PLST once enters the Playlist Edit mode.
• Pressing PLST from the Playlist Edit mode enters the Playlist Playout mode.
• Pressing PLST from the Playlist Playout mode re-cues the playlist to its
beginning.
• Pressing 3 times PLST will always cue up the playlist ready to roll.
To play back a playlist that has been cued, press the PLAY button and it will roll
at the preset speeds.
