2.5 TRANSPORT CONTROLS
2.5.1 JOG DIAL
The JOG DIAL allows the operator to pass into Search mode and thus to
choose exactly the Short OUT or Short IN image. Move the jog dial clockwise to
search forward and move it counter-clockwise to search backwards. One revolution
of the jog dial will produce a jump of approximately 35 frames. This number can be
multiplied by enabling the Fast mode. The multiplication factor is defined in the
Setup menu.
Note
The jog dial is also used to do the following:
• Set parameters in the Setup menu. Refer to the Setup menu section for
more information.
• Browse inside the clips database, the cue points or the current playlist.
Refer to the explanation of the BROWSE function for more details.
The jog dial is active at all times when the system is in Play and Record modes.
2.5.2 LEVER
The LEVER is used to start a play or to modify slow motion speed. Its travel
can be of two different types regarding the lever mode.
In this mode, the lever travel goes from 0 up to 100%.
Different ranges are available to play material from –400% to 400% (see Setup
menu - page 6.1 - F5 for selection).
To gain access to this second speed range, press SHIFT + the Lever key from the
remote controller.
Note
When SD SUPER MOTION material is loaded on the primary channel, the
lever range as a larger, flat step at 33%.
With HD SUPER MOTION, the step is at 33% or 50% depending on the
camera.
The lever is also used to adjust speed, effects type and duration in Playlist Edit
mode.
