Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
6
6. Operational Block 2
PLAY Initiates playback.
Network Not used on XTnano.
Last Cue Re-cues EVS server to previous cue point.
Goto TC Allows timecode entry, with «F» keys.
Fast Jog Used with jog dial for rapid, manual re-cue. This mode is
automatically reset after PLAY/LIVE commands.
Mark Used to enter re-usable cue point (256 cycling cues).
RECORD Initiates “E2E” mode.
Return Inside a clip, allows the operator to return to the same
picture inside the record train, if it still exists.
PRV CTL Enables/disables the Preview Control mode.
Page Selects current clip page, from 1 to 10.
7. LCD Display Provides current status of the system.
2.2 LED COLORS
A selected key lights red.
When a key lights green, it means a value in relation with this key exists.
For example: F1 to F10 keys
• Green light means a clip has been stored in relation with the key.
• Green flashing light means a clip is being created.
• Red light means the clip associated to the key is playing or is ready to play.
2.3 F-KEYS AND SMALL BUTTONS
F1 F2 F3 F4 F5 F6 F7 F8 F9 F1 0
MENU SHIFT CLEAR ENTE
R
MEN
U
This button provides access to the Secondary Menu. Also used as
CANCEL in some messages when confirmation is required.
Note: SHIFT + MENU returns to Main menu
