XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
5
Note
The operational buttons have PRIMARY and SECONDARY functions and
are divided into upper and lower sections. By pressing the SHIFT button
you gain access to the secondary functions.
1. F-keys and
small buttons
Multi-purpose keys
2. Soft keys With LCD display, allow the operator to enter the Multicam
MENU system.
3. Lever Initiates slow motion and playlist replay.
4. Jog dial Used to accurately cue disk recorder.
5. Operational block 1
PLST Initiates active playlist.
Loop This option records the main output (PGM1) to the first
input (CAM A) of Multicam.
Browse Used to browse through clips, playlists, cue points.
Insert Used in playlist management to insert clips into a playlist.
IN Sets Mark IN at the current position.
Goto IN Goes to the defined Mark IN.
OUT Sets Mark OUT at the current position.
Goto OUT Goes to the defined Mark OUT.
TAKE In PGM + PRV mode, pressing this button swaps cameras
on PGM and PRV monitors
In Multi-PGM mode, pressing this button toggles between
CAM selection and PGM selection modes.
In 2 PGM mode, when both PGMs are selected on the
Remote Panel, pressing this button swaps the content
loaded on PGM1 with the one loaded on PGM2 and vice-
versa.
In Playlist Edit mode, pressing this button inserts the clip
loaded on the PRV channel into current playlist.
Lever Changes the lever range to secondary mode (see setup
menu for range selection).
