XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
3
1.2 CONFIGURATION ON NANO REMOTE
Before you start using the Multicam application in Sportlight mode, you need to
ensure that the parameters are properly defined in the Setup menu of the nano
Remote Panel, and in the Setup Configuration module of the Multicam application.
The new parameters are saved as soon as they are modified.
Important
Prior to using Multicam, the operator should enter the Setup menu and
set all necessary parameters. If clips are stored with certain parameters
and the operator wishes to change them afterwards, those clips and
playlists will not change. It is thus important to set these parameters first.
The Multicam Configuration manual includes a detailed description of all settings
which can be defined on the Remote Panel.
