INSTALLATION MANUAL XSQUARE Version 2.
INSTALLATION MANUAL Xsquare 2.1 Copyright EVS Broadcast Equipment S.A. – Copyright © 2012-2013. All rights reserved. Disclaimer The information in this manual is furnished for informational use only and subject to change without notice. While every effort has been made to ensure that the information contained in this user manual is accurate, up-to-date and reliable, EVS Broadcast Equipment cannot be held responsible for inaccuracies or errors that may appear in this publication.
INSTALLATION MANUAL Xsquare 2.1 Table of Contents TABLE OF CONTENTS ............................................................................ III 1. XSQUARE OVERVIEW ....................................................................... 4 2. SOFTWARE INSTALLATION ............................................................. 5 3. XSECURE MANAGEMENT................................................................. 8 3.1 Introduction ...................................................................
EVS Broadcast Equipment S.A. 1. Issue 2.1.A June 2013 Xsquare Overview The goal of the Xsquare solution is to act as an orchestrator receiving job requests and dispatching them to the best engine (loadbalancing, JOB API, etc), which means an engine available and able to manage the requested job (transcoding, rewrap, etc). The engines will first be limited to XTAccess. All the jobs for XTAccess will go through Xsquare, which will be the central point to control XTAccess.
INSTALLATION MANUAL Xsquare 2.1 2. Software Installation The installation package is based on a suite of software with one installer and subinstallers in subfolders. In the Installers folder you can retrieve all sub-installers (the EVS Software and Microsoft required software). The Microsoft required software could be removed from the package in case of Update. To install the Xsquare suite, proceed as follows: 1. Copy the package in a temp directory (e.g. C:\Install Software\Xsquare\). 2.
EVS Broadcast Equipment S.A. Issue 2.1.A June 2013 3. Press NEXT. 4. Select the destination directory to install the new software and then press NEXT.
INSTALLATION MANUAL Xsquare 2.1 5. You can select here the different Xsquare modes: • StandAlone setup: The installer will install Xsquare, XTAccess and all the required software. The installer will also automatically associate XTAccess to Xsquare. This Installation mode will not ask other confirmations or questions. • Orchestrator setup: The installer will install Xsquare and all the required software but not XTAccess. This Installation mode will not ask other confirmations or questions.
EVS Broadcast Equipment S.A. 3. XSecure Management 3.1 Introduction Issue 2.1.A June 2013 To be able to manage more than 4 XTAccess with Xsquare and to be able to have the Xsquare user rights, it is necessary to have an Xsquare license. XSecure uses hardware information from the device where Xsquare is running. This means that it is impossible to exchange licenses or codes between devices. Please refer to the XSecure user manual to: 3.2 • Start XSecure Manager.
INSTALLATION MANUAL Xsquare 2.
