11.8 PLAYOUT FUNCTIONS WITH PLAYLISTS
11.8.1 ROLLING A PLAYLIST
ROLLING ACTION
After recalling a playlist, you will roll the playlist using the pre-defined speed of
each clip. Use the PLAY key to start rolling the playlist.
PLAYLIST SPEED
The playlist speed is defined in the playlist.
If the speed for a Super Motion clip
is set to “UNK”, pressing the PLAY key on that
clip will start the playback of the playlist at 33%.
11.8.2 FUNCTIONS AVAILABLE FROM THE VGA PLAYLIST SCREEN
To use the following commands, you must be in Playlist Edit or Playlist Playout
mode:
• To enter the Playlist Edit mode, press the PLST key on the EVS Remote. The
LCD screen of the Remote displays the information about the previous, current
and next 3 clips of the playlist.
• To enter the Playlist Playout mode, press the PLST key again.
The following operations can be performed from the VGA playlist screen:
Criteria Description
Naming a
playlist
For more information, refer to the section 11.6.1 ‘How to Name
a
Playlist From the VGA Playlist Bank Screen’, on page 88.
Naming the
current clip
For more information, refer to the section 11.6.3 'How to Name
the Current Element in the Loaded Playlist’, on page 88.
PLAY/pause Press ALT + P to start the playback / pause of the playlist from
the current position.
PL11 LSM01 Paola LOC TDUR=00:00:02:22
111A/04 Clipname0123 00:00:29 Unk W00:10
112B Clipname4567 00:53:29 Unk W00:10
112B/02 Clipname8910 00:53:29 Unk W00:10
Effect Edit All
Insert Speed FX Dur Delete
