Issue
10.03.A
XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
82
11.2 PLAYLIST MODES ON THE REMOTE
PANEL
11.2.1 INTRODUCTION
Two modes are available on the Remote Panel to access and manipulate the
playlists: The Playlist Edit mode and the Playlist Playout mode:
• The Playlist Edit mode is used to modify the playlist.
• The Playlist Playout mode is used to roll the playlist on air.
Editing the playlist in Playlist Playout mode is not possible.
11.2.2 ACCESSING THE PLAYLIST EDIT MODE
ACCESS
When you load a playlist pressing the PLST key on the Remote Panel, you directly
enter the Playlist Edit mode. The first frame of the element highlighted in the
playlist appears on the PGM. At the start, full control will be on the PGM side;
scrolling through the playlist can be done here.
From the Playlist Playout mode, you need to press the EDIT function (D button) or
move the jog dial to return to the Playlist Edition mode from where you can edit
the playlist.
OVERVIEW
The main menu in the Playlist Edit mode available on the Remote Panel display is
the following:
Effect Edit All
Insert Speed FX Dur Delete
A secondary menu is also available when you select MENU from the main menu in
the Playlist Edit mode. All commands are not always available in the secondary
menu:
Clr Unav. OtherAng
Replace MakeLoc Redo Undo
In Playlist Edit mode, the duration displayed in the top right corner of the LCD
screen is the playlist total duration, from the beginning to the end
.
For more details on the main and secondary menus of the Playlist Edit mode, refer
to the section 11.9 ‘Overview of Editing Functions in Playlist Edit Mode’, on page
92.
