XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
81
11. Playlist Management
11.1 GENERAL INFORMATION
PLAYLIST CREATION
Playlists can be created on the server
• via the XSense Remote Panel and/or the Multicam user interface
• by means of the Playlist Panel application in IPDirector
• via external protocols..
LIMITATION ON PLAYLIST AND TIMELINE ELEMENTS
A playlist can include up to 1000 elements.
Up to 16000 playlist elements can be saved on a server.
Up to 48000 temporary playlist elements, available for undo and redo actions, can
be stored on a server. They will be purged each time the Multicam application is
closed.
PLAYLIST LOCATION
All playlists created are automatically stored on the banks dedicated to playlists
and timelines on the server, i.e. the bank 10 of each page.
Playlists on page 10 are not available from the EVS Remote Panel. These playlists
are reserved for external protocols (Odetics, Louth VDCP, EVS AVSP).
REFRESHING THE PLAYLIST INFORMATION
Playlist information is not permanently refreshed on the network. The playlist
information for a remote playlist bank is only transferred when entering that bank.
If you are already connected to a remote playlist bank, you need to press
SHIFT+F10 again to refresh the playlist information for this bank.
