Issue
10.03.A
XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
80
To search only for a specific date, use the same date twice in the From Date and
To Date fields.
Once a date is entered, pressing Clear SHIFT+C or Clear SHIFT+D reset the
FromDate or ToDate to the default parameter (dd/mm/yy).
RESET
The RESET key: resets the default values of the search criteria (no from/to date)
and set the default TC to the TC of loaded on the PGM.
RETURN
The RETURN key (A) is used to exit the Search function without performing any
search.
Search LOC / Search NET
Once the search criteria are defined, press SRCH LOC (C) to search the local
clips database, or SRCH NET (D) to search the entire network database.
The matching clips are the ones that contain all keywords used as search criteria,
and that have at least
the requested ranking.
If matching clips are found, the remote will automatically be in Browse mode (the
BROWSE key is red), allowing the operator to quickly view the Short IN of each
clip corresponding to the search criteria by rotating the jog dial. To be able to jog
inside a clip, disable the Browse mode by pressing on the BROWSE key and move
the jog dial. To return to the Browse mode inside the search results, press the
BROWSE key again.
Search results are reset when going by to LIVE mode, or when a new search is
performed.
If no matching clips are found, a message notifies the operator.
Adding the search results to the current playlist
It is possible to directly add all search results (clips only) to the current playlist.
Press ENTER on the selected clip to insert only that one.
Press SHIFT+ENTER to insert all clips to the end of the current playlist.
