10.4.3 ASSIGNING KEYWORDS IN NUMERIC MODE
To assign keywords to a clip in numeric mode, recall the clip, then press MENU to
access the secondary clip menu on the Remote Panel.
Enter the keyword position in the list using the F_ keys. Every time a new digit is
entered, the corresponding keyword is displayed in the highlighted area in the
centre of the LCD screen, to allow the operator to validate the entry before
confirming it. If a wrong digit is entered, press the CLEAR key to delete it. Once
the right keyword is found, press ENTER to confirm or MENU to cancel.
The rules for keyword assignment and deleting keywords are identical between
LIST and NUMERIC modes.
10.5 SEARCHING THE DATABASE USING THE
REMOTE PANEL
Keywords and ranking assigned to clips can be used to search the clips database.
When the current element on the primary channel is a record train, the Search
function is directly available from the C position in the secondary menu. To call it,
press MENU to enter the secondary train menu, then press once the C key.
When the current element on the primary channel is a clip, the Search function is
still available from the same location, but it is “hidden” behind the Name function.
To call it in this case, press MENU to enter the secondary clip menu, then press
twice the C key.
In both cases, the LCD display becomes (in LIST mode):
1
player_B10123 2 2action_689012 3 keyword89012
action_889012 111A
Enter keyword # 8 with F_ keys + ENTER
Push Aux Clip Sort->TC PostRoll
>Archive *** Name Cam
