current picture is the Short IN point of the clip.
If all 3 keywords location are occupied, the operator has to clear some of them to
be able to assign a new keyword to that clip.
To clear one of the keywords already assigned, press CLEAR + F1 / F2 / F3 in the
secondary clip menu.
The clip can also be named based on the keywords. Press the Name function (C
key) in the secondary menu, then select keywords. The keywords will be added to
the name of the clip, up to 12 characters. In this mode, the name of the clip is
visible on the OSD. It can also be edited with the following keys:
• CLEAR: erase the last character
• SHIFT+CLEAR: insert a blank
• SHIFT+F1-F10: insert a number (1, 2, 3, …, 8, 9, 0)
Once the name is complete, press ENTER to validate or MENU to cancel.
While the operator is in the secondary menu, he has full control of the current clip
with the PLAY key and jog dial, so he can browse the clip and start a replay at
any time.
It is also possible to assign keywords and ranking to a clip before it is created
.
Indeed, when a record train is loaded, as soon as the operator marks an IN or
OUT point, the main and secondary menu changes to make the keyword functions
available.
The SHIFT+A function of the main menu, normally used by the Reset CAM
function, can be used to define the ranking, without entering the secondary menu.
For additional functions like selecting keywords, flagging the future clip for
archiving, marking it to be pushed to another machine, defining its name from the
keywords, they can be performed from the secondary menu, exactly the same way
as for a clip already stored. All these settings are memorized and will be applied
to the clip when it is created.
PGM1 Cam A *PRV1* Cam B
Push PgmSpd Sw To In Pref
>Archive *** Name Cam
P.1 B.1 Clips: Local Records: Local
PL 11: < >
Msg:
***
Local Sync Prv 2nd CTRL
Cam A Cam B Cam C Cam D
