10.4 ASSIGNING KEYWORDS USING THE
REMOTE PANEL
10.4.1 KEYWORD SETTINGS
A keywords file must be selected in the Setup to enable the keyword assignment
functions on the EVS Remote Panel.
• In the Setup menu of the remote, the operator can choose between 2 different
keyword modes: “List” (default) or “Numeric”.
• In LIST mode, the list of keywords will appear on the LCD display by group of 8
keywords, and the operator can select the keyword by pressing the
corresponding F_ key. The advantage is that the keywords are visible to the
operator, but this mode can be slow if he has to browse through a long list of
keywords.
• In NUMERIC mode, the list of keywords is not visible on the LCD display, and
the operator selects a keyword by entering its position in the list with the F_
keys. He can know the position either from a hardcopy of the keywords list, or
by looking at one of the VGA Keywords screens, or still from his memory... This
mode is faster to operate, but in most cases the operator will need to have the
complete list of keywords available next to him.
10.4.2 ASSIGNING KEYWORDS IN LIST MODE
To assign keywords to a clip in list mode, recall the clip, then press MENU to
access the secondary clip menu on the Remote Panel.
The LCD display a page containing 8 keywords. Press F9/F10 to access the
previous/next keywords page. To assign a keyword to the current clip, press the
F_ key corresponding to the desired keyword on the LCD display.
Depending on the CLIP/CAM mode defined by the D key, the selected keyword will
be assigned only to the camera angles loaded on the channels fully controlled by
the operator at that time (CAM mode), or to all camera angles of the clip (CLIP
mode). The keyword will be assigned to the first available keyword location on the
1
st
line of the LCD display. If the Keyword Info parameter of the Setup is set to
“Yes”, it will also appear on the OSD of the corresponding output monitors if the
1
player_B10123 2 action_689012 3 keyword89012
F1:action_1 F6:action_6
F2:action_2 F7:action_7 111A
F3:action_3 F8:action_8
F4:action_4 F9:Prev.page p.01
F5:action_5 F0:Next page
Push Aux Clip Sort->TC Post-Roll
>Archive *** Name Cam
