Issue
10.03.A
XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
72
Criteria Description
Timecode This restricts the search to the clips containing the timecode
specified in this field. The timecode search is not applied on
growing clips.
To define a timecode, type the desired value when the red text
cursor is visible in that field.
The <BACKSPACE> key can be used to clear the last digit
entered.
Date from / to This restricts the search to clips created between these 2 dates
specified in these fields.
If only Date to field is defined, all clips created before that date
will be considered.
If only Date from field is defined, all clips created after that date
will be considered.
The <BACKSPACE> key can be used to clear the last digit
entered. Press the <TAB> key again to move the cursor back to
the keywords list.
Level /
Ranking
This restricts the search to the clips with a ranking equal or
higher to the ranking defined in that screen.
Press the ←/→ arrow keys until reaching the desired ranking,
and press ENTER. The selected ranking is highlighted in green.
Press the <TAB> key again to move the cursor back to the
keywords list.
Keywords This restricts the search to the clips containing all keywords
defined in this screen.
To assign a keyword, move the cursor to the desired keyword
and press ENTER, or click on the keyword using the stylus.
A maximum of 3 keywords can be used as search criteria. If all 3
keyword locations are already occupied, the operator needs to
clear some of them to select new keywords.
Archive status This restricts the search to the clips having the archive status
selected.
Parameter On the VGA
None (default) -
clips not archived X
clips to be archived >A
clips archived A
