XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
61
4. Press ALT + S to save the clip. The Save as window opens, giving the
operator the opportunity to name / rename the clip if needed. Pressing ENTER
will save the clip to the current cursor location in the lower section of the VDR
Panel. When the Save as window is open, the operator still has the possibility
to browse the database, select a different page and bank, and even connect to
another machine on the network using the CONNECT window. Pressing ALT+U
will save the clip to the first available clip location
1
in the current server.
EDITING A CLIP WITH THE VDR PANEL PLAYER
After loading the desired clip, the following functions are available:
Command Description
ALT+N Renames the clip. Type the desired name and press
ENTER to confirm or ESC to cancel.
ALT+I / ALT+O Marks a new Short IN / Short OUT point on the current
picture. The cursor is automatically placed in the adjacent
field, so that the operator can manually enter the
timecode of the desired Short IN / Short OUT point if
needed. Press ENTER to confirm, or ESC to cancel.
HOW TO MAKE A COPY OF A CLIP WITH THE VDR PANEL
PLAYER
1. Load the original clip
2. Press ALT+S to save the current clip to another location. This will create a
copy of the clip.
The operator has the opportunity to rename the clip during this operation. He
can then save the clip to the current cursor location by pressing ENTER, or to
the first available clip location on the current server by pressing ALT+U.
Note
The Cut / Copy / Paste functions are available at any time to move and
copy clips in the lower section of the VDR Panel, even when one of the
upper windows is active.
1
The first available clip location is the first one where no camera angle is already present.
