XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
53
9.3.10 RECALLING A CLIP
HOW TO CALL A CLIP BELONGING TO THE MACHINE YOU ARE
CONNECTED TO
The machine to which you are connected is indicated on the left side of the Title
Bar.
To call a clip belonging to the machine you are connected to, proceed as follows:
1. Type either the 3 or 4 digits of the ID. Ex: 111 or 111A. The entry appears in
the Name field.
2. Press F3
o If only 3 digits are entered, the primary camera is selected
o If 4 digits are entered, the clip is selected according to the given camera
angle.
o If no clip matches the entry, no selection is done.
Note
ESC key can still be used at any time to clear the Name field.
HOW TO CALL A CLIP BELONGING TO ANOTHER MACHINE
THAN THE ONE YOU ARE CONNECTED TO
1. Type either the first 3 or 4 digits of the ID, followed by a “/” and the network
number of the machine. Ex: 111/03 or 111A/03. To call a local clip, no matter
what machine you are connected to, type 00 as network number. Ex: 111/00 or
111A/00.
2. Press F3.
9.3.11 HOW TO CANCEL A NETWORK COPY ON THE VGA
Select the clip and press the CTRL+DELETE keys. A confirmation screen comes
up. “Cancel network copy? ESC: Do not cancel copy - ENTER: Cancel copy”
If the Copy Clip option copies several cams of the same clip and some of them
have already been copied before the Cancel function, the cancel does not do a
delete of the copied files, it just cancels the cam(s) still copying or to be copied of
that clip. It does not cancel the copying of other clips.
The Cancel function remains possible even if the page where the clip is being
copied is protected.
