Issue
10.03.A
XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
38
9.2.6 CLEARING CLIPS
WHICH CLIPS CAN BE DELETED?
You can clear clips available on disks or growing clips.
The function key that corresponds to the clip location on the Remote Panel must
be green for the user to be able to delete it:
• Loaded clips cannot be deleted.
• Clips included in a playlist or currently used by another operator, cannot be
cleared either in network mode.
In all cases, a warning message will appear.
HOW TO CLEAR A CLIP
To clear a clip, proceed as follows:
1. Select the appropriate page and bank where the clip to be erased is stored.
2. Press CLEAR, followed by the F_ key that corresponds to the clip.
Attention: In most cases, no confirmation is required and the clip will be
instantly deleted.
3. If the clip is protected or if the Confirm Delete Clip parameter is set in the
Setup menu, a warning message appears.
4. Press ENTER to confirm and the selected clip will be erased.
HOW TO CLEAR UNPROTECTED CLIPS IN A BANK?
To clear all unprotected clips stored on a given bank, proceed as follows:
1. Select the page that includes the bank on which you want to delete the
unprotected clips in a clip bank.
2. Press CLEAR + SHIFT, and the F_ key that corresponds to the requested
clip bank.
The following confirmation message will be displayed:
Caution:
This will delete all unprotected clips
stored on bank X
[Menu] : Cancel [Enter] : Confirm
3. Press ENTER to confirm and the unprotected clips on the bank are deleted.
