9.2.4 PLAYING BACK A CLIP
PLAYBACK SPEED FEATURES
You can play back a clip using several playback speed features explained above
in this user manual. This section summarizes the various playback speed features
and refers to more detailed sections on these features:
• Playback of a clip at the default playback speed using the PLAY key
• Playback of a clip at a given predefined speed defined in the PgmSpd/Var Max
setting on the Remote Panel (Pg. 6.1, F3).
To use this feature, you need to activate the PGM Spd option available from
the secondary menu in PGM/PRV mode. For more information, refer to the
section ‘PgmSpd/VarMax’, on page 24.
HOW TO PLAY BACK A CLIP
To play back a clip, proceed as follows:
1. Store a clip.
2. Recall the defined clip which will be played, the corresponding F_ key lights
red.
3. To start playing back the clip, press the PLAY key.
9.2.5 RECALL AND PLAYBACK OF GROWING CLIPS
You can recall and play growing clips, i.e. clips that are in the process of being
created on a disk.
As long as the OUT point of a growing clip is not available on the EVS server, the
LED corresponding to the growing clip location blinks green when it is called and
red when it is loaded on the Remote Panel. The clip LED will no longer blink as
soon as both IN and OUT points are available on the EVS server.
If the play reaches the end of the available material, the play will freeze until new
material is available for playout. When new material is available, the play
resumes.
When the OUT point of the clip is known, the remaining time is displayed.
When the OUT point of the clip is not known, the remaining time display switches
to --:--:--:-- until the entire clip is copied.
