XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
35
A clip can be created with only IN point or only OUT point. The system will
automatically define the clip duration according to the default duration defined in
the Setup menu.
Note
You can mark an IN or OUT point on a paused record train and go back to
live without losing the point marked by pressing SHIFT-<Return>.
9.2.2 STORING A CLIP
HOW TO STORE A CLIP
To store a clip on a given location, proceed as follows:
1. Define a clip by marking the IN and/or OUT points
2. Select the page where the clip will be stored by pressing SHIFT + PAGE +
F_ key corresponding to the page.
Page 1 contains clips 110 to 199. Page 2 contains clip 210 to 299, and so
on.
3. Select the bank where the clip will be stored by pressing SHIFT + F_ key
corresponding to the bank.
4. Select the location of the clip to store by pressing the corresponding F_ key.
The clip is created on the specified location. The primary timecode of the clip is
the primary timecode defined on the train where and when the clip has been
created.
EXAMPLE
To create the clip on the position n°212 (page 2, bank 1, clip location 2):
1. Press SHIFT+PAGE+ F2 to select page 2.
2. Press SHIFT+F1 to select bank n°1.
3. Press F2 to select location n°2 on the selected page and bank.
Important
The AUTO-SAVE process automatically saves clips and playlists
at least every minute. With Multicam 5.03.25 or higher, playlists
are included in the AUTO-SAVE process. Exiting the software
(ALT+Q) or doing “Save Clips+Plst” from the main menu will also
save the clips and playlists.
