Note
• Protect IN & Protect OUT points of a clip cannot be replaced by new
ones.
• Short IN & Short OUT points of a clip can be replaced by new ones.
• Short OUT point is excluded. The clip freezes on previous field when
playing back (with Post-Roll disabled).
• (Short) IN & OUT are always on even fields. This is automatic.
• The guardband beyond the Short OUT point is created with the material
available when the operator saves the clip by pressing the selected F_
key. Therefore, this guardband can sometimes be shorter than the
value defined in the Setup menu.
9.1.2 CLIP AVAILABILITY ON DISKS
Various clip types can be distinguished depending on whether they are available
on the disks or not. Depending on the clip availability on disks, you can perform
specific actions on the given clip or not.
Clip on disk Clips which are protected on disks, and which have Short
IN and Short OUT points present on disks.
All the material is available on the disk.
Growing clip Clips which are protected on disks, and which have a Short
IN point, and possibly Short OUT point defined on disks.
Since the record process is still undergoing, some of the
material is already on the disk but not all of it.
Reserved clip Clips for which the position has been reserved on the SDTI
database but for which there is no Short IN and Short OUT
points, nor any protect present on disks.
9.2 USING THE EVS REMOTE PANEL
9.2.1 HOW TO CREATE A CLIP
To define a clip, proceed as follows:
1. Select the LIVE mode.
2. Using the jog dial, define your Short IN point. Press the IN key to mark your
Short IN point of the clip.
3. Search for the desired Short OUT point and then press the OUT key to mark
it.
