4.1.8 FAST JOG
When selected, this option enables fast picture search: the actual speed of this
fast jog is adjustable in the Setup menu. Starting a play or returning to E2E mode
resets the Fast Jog mode.
Important
The jog dial is active at all times when the system is in play & record.
The brake is automatically turned on when starting a playback with the
PLAY key, or when returning to E2E mode with the RECORD button.
4.1.9 PLST
This function is not active if the current playlist is empty. If the current playlist is
not empty, pressing PLST once enters the Playlist Edit mode.
• Pressing PLST from the Playlist Edit mode enters the Playlist Playout mode.
• Pressing PLST from the Playlist Playout mode re-cues the playlist to its
beginning.
• Pressing 3 times PLST will always cue up the playlist ready to roll.
To play back a playlist that has been cued, press the PLAY button and it will roll
at the preset speeds.
4.1.10 BROWSE
When a clip is loaded on the primary channel, pressing the BROWSE key allows
the operator to browse inside all local clips of the database by turning the jog dial.
When a cue point exists for the current picture on the primary channel (the CUE
button lights red), pressing the BROWSE key allows the operator to browse
through all existing cue points by turning the jog dial.
When the current picture on the primary channel is neither a clip nor a cue point,
or if the operator is in Playlist mode, pressing the BROWSE key allows him to
browse inside the clips of the current playlist by turning the jog dial.
4.1.11 INSERT
This function inserts a clip before or after (depending on the Setup menu) the
current position inside the playlist.
4.1.12 ENTER
This function appends clip(s) at the end of the current playlist. This is also used to
confirm saving of clips, and validate various options and messages.
