13.4.4 HOW TO INSERT REMOTE CLIPS INTO A PLAYLIST
1. Select the remote EVS server via the Network menu.
2. Select a remote clip in the banks. The corresponding F_ key lights red.
3. Press ENTER on the Remote.
4. Repeat the 3 first steps as necessary until last clip is entered.
In Playlist Edit mode, the remote display gives all needed information regarding
this playlist and this information is updated each time a clip is stored in the
playlist.
13.4.5 HOW TO ROLL A PLAYLIST WITH REMOTE CLIPS
1. Once the playlist is cued and ready to roll, select the playlist from the playlist
bank.
2. Press the PLST key on the Remote Panel.
3. Press the PLAY key to start the playback.
CLIPS UNAVAILABLE ON THE XNET NETWORK
While the playlist is rolling on air, a remote clip might be unavailable due to a
network problem or simply if the remote EVS server has left the network. In this
case, the clip is marked as ‘NOT AVAILABLE’ on the playlist screen and is skipped
when the playlist is rolling. If a clip is made available again, it will re-appear
automatically and be played at the right position in the playlist.
Unavailable clips are shown on the VGA monitor but not on the LCD of the remote.
The operator can decide to definitively remove the unavailable clips from all local
playlists by using the Clr Unav. function (SHIFT+B) in Playlist Edit mode. Note
that this function is only visible when unavailable clips are present and with Split
Audio Editing turned off.
PL11 LSM01 MICHEL LOC TDUR=00:00:58:22
152A/03 Clip 0112 00:01:20 Unk W00:10
111A/04 Clip Foot 00:10:25 Unk W00:10
112B Clipname4567 00:04:29 Unk W00:10
112B/02 Clip 0113 00:01:10 Unk W00:10
552C/08 noname01234 00:02:50 Unk W00:10
EFFECT EDIT ALL
INSERT SPEED FX Dur DELETE
