13. Operating on XNet
Network
13.1 INTRODUCTION
The XNet Network is set up in the EVS application. For more information, on how
to set up the XNet Network and connect to the XNet network, refer to the section
XNet SDTI Network in the Multicam Configuration manual and to the XT Tech Ref
Software manual.
13.2 DISCONNECTING FROM XNET
When you work on the XNet Network and exit Multicam, the system checks if other
systems are still connected to your server.
In this case, the following message appears:
Other users are connected to your LSM
on XNet network. Are you really sure that
you want to close the Multicam application ?
[ESC] =CANCEL [ENTER]=YES
Press ESC to cancel the command and return to the application.
Press ENTER to exit the Multicam application.
13.3 SELECTING A SERVER ON XNET
Selecting the NETWORK key (SHIFT + PLAY on the Remote) displays the Network
menu:
Select a LSM on XNET Page 1/4
F1 MICHEL F6 MACHINE6
F2 PIERRE F7 MACHINE7
F3 PAUL F8 MACHINE8
F4 JACQUES F9 MACHINE9
F5 ANDRE (LOCAL) F0 MACHINE0
Previous Next
Local Clips Records Clip+Rec
