12.2 CREATING TIMELINES
In Multicam, the timelines have to be created from an existing playlist or copied
from an existing timeline. After the transformation, the duration of the timeline
cannot be changed.
Note
It is not allowed to insert growing clips in a timeline.
12.2.1 HOW TO CREATE A TIMELINE FROM A PLAYLIST FROM THE
REMOTE PANEL
To transform a playlist to a timeline with the Remote Panel, proceed as follows:
1. Select the playlist you want to convert.
2. Press an empty playlist position.
3. Select the CopyToTL option (B) on the Remote to copy the playlist to a
timeline on the selected empty position.
4. Press ENTER on the Remote to confirm the CopyToTL
The playlist is converted into a timeline at the playlist position you selected.
12.2.2 HOW TO CREATE A TIMELINE FROM A PLAYLIST FROM THE
VGA
To transform a playlist to a timeline in the VGA, proceed as follows:
1. Select the playlist you want to convert.
2. Press CTRL+C on the keyboard to copy it.
3. Paste it into an empty playlist position using the CTRL+T keys (rather than
CTRL+V)
The timeline appears on the Remote as “TL” for timeline, rather than “PL” for
playlists. On the Clip screen, they appear with a blue background (similar to the
protected clip identifier).
All audio tracks in the playlist are placed on the timeline as follows:
• each timeline has two audio edit tracks containing each single audio.
• Independently from the audio configuration, the first audio input is edited on the
first audio track, the second input on the second audio track.
• The parameter ‘Mono per Track’ on page 3.4 (F2) can be used to set how many
audio mono tracks can be used for each edit track.
