XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
5
Note
The operational buttons have PRIMARY and SECONDARY functions and
are divided into upper and lower sections. By pressing the SHIFT button
you gain access to the secondary functions.
1. F-keys & small
buttons
Multi-purpose keys
2. Soft keys With LCD display, allows the operator to enter the
Multicam MENU system
3. Jog dial Used to accurately cue disk recorder
4. Operational
block 1
PLST Initiates active playlist
LOOP This option records the main output (PGM1) to the first
input (CAM A) of Multicam.
BROWSE Used to browse through clips, playlists, cue points
INSERT Used in playlist management to insert clips into a
playlist
IN Sets Mark IN at the current position
GOTO IN Goes to the defined Mark IN
OUT Sets Mark OUT at the current position
GOTO OUT Goes to the defined Mark OUT
TAKE In PGM+PRV mode, pressing this button swaps cameras
on PGM and PRV monitors
In Multi-PGM mode, pressing this button toggles
between CAM selection and PGM selection modes.
In 2 PGM mode, when both PGMs are selected on the
Remote Panel, pressing this button swaps the content
loaded on PGM1 with the one loaded on PGM2 and vice-
versa.
In Playlist Edit mode, pressing this button inserts the
clip loaded on the PRV channel into current playlist.
