XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
129
Those IN and OUT points will be used to determine what portion of the playlist will
be replaced.
THE REPLACE PLAYBACK MODE
In this mode, you play the playlist back and insert the new section between the
defined IN and OUT points.
After you have selected the required settings for the Replace function, the
Replace Playback mode is automatically activated: the playlist is cued before the
IN point (to create guardbands), ready to be initiated.
The playlist is played at the speed defined in the playlist.
When the Protect OUT point of the clip is reached, a clip containing the IN and
OUT point with the guardbands is created on the Receive page defined in the
Setup menu. The loop is stopped and the user switches back to match frame edit
mode.
11.17.4 REPLACE WITH IN/OUT POINTS OR WITH IN POINT ONLY
You can perform a Replace action in two ways:
• by defining an IN and OUT points in the Replace Edit mode.
• by defining only an IN point in the Replace Edit mode, and defining the OUT
point while you perform the Replace in the Replace Playback mode.
For more information on how to perform a Replace, refer to the section ‘How to
P
erform a Replace’, on page 129.
Impor
tant
The IN and OUT points cannot be marked on a transition (including split
audio transitions and swap zones) or on a split zone (the key will flash
red when it is the case).
11.17.5 HOW TO PERFORM A REPLACE
You first define the Replace function in the Replace Edit mode. Then, you execute
the Replace function in the Replace Playback mode.
To perform a Replace, proceed as follows:
1. Open the playlist in which you want to replace a section in Playlist Edit
mode.
2. In Playlist Edit mode, press Menu on the Remote Panel to access the
secondary menu.
3. Press the A key to enter the Replace Edit mode.
4. Use the jog dial to reach the desired IN point for the Replace section and
press the IN key to mark it.
When the IN point has been marked, the display switches to:
