11.16 SWAP AUDIO TRACKS
11.16.1 INTRODUCTION
The swap audio tracks mode allows swapping audio tracks between two points in a
playlist.
In four tracks mode, the “auto” mode replaces audio tracks 1&2 by audio tracks
3&4 in four audio mode. It replaces audio track 1 by audio track 2 in stereo mode.
The manual mode lets you choose which tracks to replace.
Note
In 8 and 16 tracks mode, you only have access to the manual mode.
11.16.2 HOW TO ENABLE THE AUDIO SWAP MODE
To enable the Audio Swap mode, proceed as follows:
1. Enter the Setup menu.
2. Select the Swap Audio Tracks mode on page 4.2, F3.
3. Choose a value between “Auto” and “Manual”.
Please note that the Split Audio Editing has to be enabled in the Setup menu
on Page 4.2, F1. This option requires a specific license code. If that code is
not installed on the server, this option cannot be turned on.
11.16.3 HOW TO PERFORM A SWAP AUDIO TRACK IN AUTO MODE
1. In Playlist Edit mode, select the Video Base mode (V Base). The LCD screen
will now display additional function:
2. Press the Swap button.
3. Jog your playlist until you reach the point where you want to change the audio
tracks. Mark an IN point.
The OSD screen indicates the following information:
In dual stereo mode
PL11 LSM01 Paola LOC TDUR=00:00:02:22
111A/04 Clipname0123 00:00:29 Unk W00:10
112B Clipname4567 00:53:29 Unk W00:10
112B/02 Clipname8910 00:53:29 Unk W00:10
V Base A Base Swap
A Advanc A Delay A FX DUR A Split
