XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
115
Audio Effect
Cut Mix Fade
from
Mute
Fade to
Mute
V Fade
to/from
Mute
Video Effect
Fade from color √
Fade to color √
V Fade (to/from Black) √
11.15.6 DEFAULT MODE FOR EXTENDING A TRANSITION
INTRODUCTION
Whenever you make a video or audio split, the transition originally set is changed,
which means extended on either or both sides of the transition boundaries. In the
Setup menu, page 4.2, key F2, you can set the default mode for extending
transition effects, this means you specify where the effect is extended.
T
RANSITION MODES
The following table summarizes the various transition modes:
Criteria Description
Center (on) Cut The transition is extended equally in both directions. This is the
default value.
End (on) Cut The transition is extended to the left, so that the end of the
transition is not changed.
Start (on) Cut The transition is extended to the right, so that the start of the
transition is not changed.
Ask Asks the operator to choose one of the 3 options above each
time he edits a transition.
POSSIBLE CASES
You can build different types of playlists depending on:
• the transition mode in video or audio split
• the transition duration
