11.15.4 DEFAULT DURATION FOR THE AUDIO AND VIDEO
TRANSITIONS
GENERAL USE
This is possible to set a default value for the duration of the video and audio
transitions in the Setup Menu. Once this is defined, each time a clip is entered or
inserted into a playlist, transitions are applied with the default values.
The Vid. Effect duration setting is on page 4.1, function key F1 (range up to
20:00 secs).
The Aud. Effect duration setting is on page 4.1, function key F2 (range “Lock to
video”, then up to 20:00secs).
USE WITH SPLIT AUDIO
The simplest type of Split Audio edit that can be performed on an XSense is to
make the video and audio transitions at the beginning of the clip have different
durations, such as a 12 Frame Video Mix with a 2 sec Audio cross fade.
The value of the Audio Effect Duration parameter of the Setup menu (p. 4.1, F2
key) is only taken into account when the Split Audio mode is enabled. Otherwise,
the audio effect duration is always locked to the video effect duration, whatever
the value of these parameters.
If the Audio Effect Duration parameter in the setup is set to ‘Lock to video’, it
will never be possible to adjust independently the duration of the audio and video
transitions. If you want to adjust one of these transitions and the other one
follows, please check the Audio Effect Duration in the setup, and make sure it is
NOT set to “Lock to Video”.
11.15.5 ASSOCIATIONS OF AUDIO AND VIDEO TRANSITION TYPES
The following table shows the possible associations of audio and video transition
effects when the Audio Effect Duration parameter is not lock to the video (setup
menu, page 4.1):
Audio Effect
Cut Mix Fade
from
Mute
Fade to
Mute
V Fade
to/from
Mute
Video Effect
Cut √ √
Mix √
Wipe Left -> Right √
Wipe Right -> Left √
