XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
105
11.12.2 HOW TO SORT THE PLAYLIST ELEMENTS BY TC IN
From the VGA, it is possible to sort (reorder) the playlist elements by TC IN. The
sort is done on the TC displayed in the TC IN column, whatever the type of TC
displayed (User TC or LTC).
Note
This operation will change the order of the playlist elements, and reset
the transitions to the default transitions defined on the Remote Panel
.
To reorder the playlists elements by TC IN in a playlist, proceed as follows:
1. Open the playlist in the VGA Playlist screen.
2. Press the TAB key until you highlight the Sort by TC IN field in the Playlist
management area at the bottom of the screen.
3. Press ENTER to validate, and press ENTER a second time to confirm the
operation.
The playlist elements are reordered by TC IN.
You can undo the operation using the Undo command available in Playlist Edit
mode on the Remote Panel.
11.12.3 HOW TO MERGE PLAYLISTS
From the VGA, it is possible to merge two playlists by copying a playlist and
pasting it to an existing playlist. The copied playlist will be added at the end of the
destination playlist.
11.12.4 CONSOLIDATING A PLAYLIST
OVERVIEW
Using the internal loop, you can record a playlist back to the server as a big clip if
you want, for example, to record the playlist effects (split screen, target tracking,
painting, etc) as regular video inside the server.
Depending on the Internal Loop Mode parameter in the setup menu, p2.3, F1,
both video and audio can be looped back into the system, or only the video track
is looped and the system keeps recording the live audio at the same time.
