11.10.9 HOW TO CHANGE THE CAMERA ANGLE OF A PLAYLIST
ELEMENT
You can change the camera angle of a playlist element if the material is still
available in a local or distant record train.
To change the camera angle of a playlist element, proceed as follows:
1. When you are in Playlist Edit mode, scroll within the playlist to the playlist
element for which you want to modify the camera angle.
2. Press MENU to access the secondary menu:
OtherAng
Replace MakeLoc
3. Press SHIFT+C to search and load the local and distant record trains that
include the same TC IN as the playlist element.
The first record train is loaded on the PRV channel, at the current TC of the
loaded element.
4. Press Browse and use the jog to move within one record train to browse its
content.
5. Once you have loaded the requested camera angle on the PRV channel,
press ENTER.
This will replace the current playlist element by a new clip having the same TC IN
and TC OUT. The new clip is stored on the playlist receive page. The effects, split
audio and swap points defined on the initial playlist element are preserved.
