2. Press MENU + C to enter the Search mode:
Enter the search criteria as explained in the section 10.5 ‘Searching the
Da
tabase using the Remote Panel’, on page 78.
3.
Launch the search on the local server or on the whole network by pressing
respectively the C (Srch Loc) or D (Srch Net) keys on the Remote Panel.
4. Do one of the following:
• To insert only one clip into the playlist, browse to the clip and press the
INSERT key on the Remote Panel.
• To insert all clips returned in the search result, press the SHIFT+ INSERT
keys on the Remote Panel.
The clip(s) are inserted at the end of the current playlist.
11.10.6 INSERTING GROWING CLIPS INTO PLAYLISTS
Growing clips can be inserted in playlists in the same way as other clips.
However, their display has the following characteristics:
Display
They will be displayed with the ‘Creating’ message in the playlist on the VGA.
The growing clips ID will be blinking on the mini playlist display and on the playlist
screen on the Remote Panel, as well as on the OSD.
