Issue
10.03.A
XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
94
REPLACE
The Replace function makes it possible to replace a portion of a playlist by the
same A/V material to which effects have been added (externally or internally).
This consolidates the effects within the playlist. For more information, refer to the
section 11.17 ‘Replace Function’, on page 128.
CLR UNAV.
The Clr Unav. (Clear Unavailable) function (SHIFT+A key) allows the user to
remove the clips that are not available on the network from all local playlists. This
function is only visible when unavailable clips are present and when the Split
Audio Editing is turned off.
MAKELOC
The MakeLoc (Make Local) function (B key) offers the possibility to copy locally
remote clips in a playlist. In the playlist secondary menu, select on the B position
MakeLoc.
When the function is called, the remote clips are replaced by short copies of the
local ones as soon as they are available.
UNDO/REDO
The last modifications of a playlist can be undone/redone for as long as the
operator does not exit the playlist mode (e.g.: returning to live).
Pressing the Undo command (D key) will undo the last modification. Up to 9
modifications can be undone. Once a modification has been undone, it is possible
to redo it by pressing the Redo key (C key).
OTHERANG
The OtherAng (Other Angle) function (SHIFT+C key) allows the operator to replace
the current playlist element by another playlist element showing a different angle
of the recorded material.
When the OtherAng option is selected, Multicam loads the local and network
trains that include the TC IN of the playlist element to replace. The trains are
loaded on the PRV channel, at the current TC of the loaded element. The jog is
used to shift from one record train to the other.
Once the requested record train is displayed on the PRV channel, pressing ENTER
replaces the current playlist element by the one created from the selected angle.
See also the section 11.10.9 ‘How to Change the Camera Angle of a Playlist
El
ement’, on page 99.
