XSense
–
Version 10.03
–
Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.A
93
INSERT
The Insert function (A key) allows the operator to insert a clip into the playlist.
The same operation can be achieved using the TAKE key.
See also the section 11.10.4 ‘How to Insert Clips into a Playlist’, on page 96.
SPEED
The Speed function (B key) allows defining the speed at which one or all clips of
playlist will be played. Select the playback speed of the clip with the jog, then
press ENTER to validate. Values are ‘Unknown’ and from 0 to 100%.
Operators have access to the secondary lever control like when clips are replayed.
While editing the speed of a clip, pressing SHIFT+Lever on the Remote allows to
access the secondary lever speed defined in the menu.
FX DUR
The FX Dur function (C key) sets the duration of the transition effect. The default
value that initially appears is determined by the value set in the Setup menu. The
effect duration will affect the transition at the beginning of the selected clip. Use
the jog to adjust the value, then press ENTER to confirm.
EFFECT
The Effect function (SHIFT+C key) is used to select the type of transition effect
(Mix/Wipe/Cut/Fade). Use the jog to set the type of effect, when Effect is
highlighted. Press ENTER to validate.
For more information on the effects types, refer to the section 11.14 ‘Transition
E
ffects’, on page 108.
DELETE
The Delete function allows the operator to quickly edit a playlist by removing the
selected clip. The clip that has been «cut» can then be inserted into another
location. This clip is displayed on the second PRV output. To insert it at another
position in the playlist, simply go to that position using the jog dial and press the
Insert key (or TAKE).
11.9.2 SECONDARY MENU IN PLAYLIST EDIT MODE
INTRODUCTION
You can access the secondary menu of the Playlist Edit mode pressing MENU on
the Remote Panel when you are in the main menu of the Playlist Edit mode.
Clr Unav. OtherAng
Replace MakeLoc Redo Undo
