While the playlist is rolling on air, selecting the Next function will start the
transition of the next clip with the transition effect listed on the playlist. This can
be used if a clip is running too long and it is necessary to shorten up the playing
time.
SKIP
While the playlist is rolling, the next clip in the sequence is always displayed on
the PRV screen. The Skip function allows the operator to discard clips before they
go on-air. The clip that will be «skipped» is the one displayed on the PRV screen.
This function does not remove the clip from the playlist, but it simply allows it to
be skipped during playback.
EDIT
Selecting the Edit function gets the user back to the Playlist Edit mode.
11.9 OVERVIEW OF EDITING FUNCTIONS IN
PLAYLIST EDIT MODE
The following section presents the various editing functions available from the
main and secondary Playlist Edit Mode.
11.9.1 MAIN MENU IN PLAYLIST EDIT MODE
INTRODUCTION
The main menu in the Playlist Edit mode is available when you select the location
of the requested playlist, and press PLST on the Remote Panel:
Effect Edit All
Insert Speed FX Dur Delete
In the Playlist Edit mode, the first frame of the playlist element loaded (highlighted
on the Remote Panel LCD display) can be seen on the PGM. To change any of the
options on a clip, simply browse to the requested clip, then select a function from
the menu displayed above and use the jog to adjust to the desired value (when
applicable).
EDIT ALL
If you want to edit all clips of the playlist at the same time, select Edit All
(SHIFT+D) before you perform the requested editing action with one of the
following playlist commands: Speed, Effect, FX Dur.
