Criteria Description
RECUE Press ALT + R to recue to the beginning of the playlist and
pause.
NEXT Press ALT + N while the playlist is playing to force immediately
the transition to the next clip in the playlist.
SKIP Press ALT + S while the playlist is playing to skip the next clip.
The current clip will play until the defined OUT point, than the
playlist will skip the next one and play the one after instead.
11.8.3 FUNCTIONS AVAILABLE ON THE REMOTE IN PLAYLIST
PLAYOUT MODE
Once the playlist is cued and ready to roll, the menu below is displayed on the
Remote LCD. This menu gives the operator the ability to manipulate the playlist
while it is playing. The duration displayed in the top right corner of the LCD
screen in Playlist Playout mode is the remaining duration until the end of the
playlist.
FILM FX
Selecting this function will create a film style effect during the playout of the
playlist by repeating one field every two fields. Please note that the audio is also
affected by this effect, making it unusable and therefore, muted. This mode is
deactivated when exiting a playlist.
PL11 LSM 04 Albert LOC LEFT=00:00:02:22
111A Clipname0123 00:00:29 Unk W00:10
112B/03 Clipname4567 00:53:29 Unk M00:10
112B Clipname8910 00:53:29 Unk M00:10
2nd CTRL
Film FX Next Skip Edit
