XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
63
3.4.5 Jobs Status Area
The transfer rate of the Backup and Restore processes is permanently evaluated and the
progress bars show the activities in progress.
Depending on the operations in progress, the operator has the choice between two status
displays:
Toggle to ‘Jobs done’ display
Toggle to ‘ Scheduled jobs’ display
Jobs Done Status Display
The different operations are divided into different tabs.
Filters
Use these filters to refine the selection:
Option Description
View All Displays all status since the startup of the system.
View Last Day Displays the operation status related to the last 24 hours.
View Last Hour Displays the operation status related to the last hour.
Hide Successful Brings out clearly the various errors occurring during a
complete session.
