Issue 2.19.A
XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
62
3.4.3 Network status
The icon displayed in the center of the screen notices the current status of XNet:
Connection to XNet is successfully done
XFile is connecting
Connection to XNet failed
Local hardware failure has been detected
Standalone mode
3.4.4 Disk Usage and Disk Mode
The remaining capacity and the capacity of disks are displayed in the lower part of the
window for each path.
The icon displayed in the lower part of the screen notices the current disk mode in use:
Single Disk
Dual Disk
Mirroring
