XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
47
Clip Information Description
orange background. This draws the attention to the fact
that the Restore is not possible on these files without a
manual file conversion.
Keyword 1
Displays the first keyword assigned to the clip.
Keyword 2
Displays the second keyword assigned to the clip.
Keyword 3
Displays the third keyword assigned to the clip.
Creation Date and Time
Displays the creation date and time of the EVS video
server where the clip has been created
Backup Date and Time
Displays the date and time of the XFile when the clip
backup file has been created.
Filename
Displays the name of the backup file that includes the clip.
Media Full Path
Displays the full path where the backup file is located on
the XFile disks.
Metadata Full Path
Displays the full path where the metadata XML file of the
backup file is located on the XFile disks.
Sorting Clips in the XFile List
To sort a column in alphabetical or numerical order, click on the column label to display
the arrow button and click again to invert the sorting.
