XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
41
Example of XML file for Restore command
Restore Clip I:\HD\backup133A.mxf to EVS server n°11 at 111A
<?xml version = "1.0" ?>
<EVS_XFile_Job_List>
<EVS_XFile_Job>
<Job_Id>1238431548774395</Job_Id>
<Job_Creation_Time>1129799945</Job_Creation_Time>
<Job_Type>1</Job_Type>
<Job_Src_File>I:\HD \backup133A.mxf</Job_Src_File>
<Job_Src_Id>9YYabjA0</Job_Src_Id>
<Job_Src_Id_Material>9YYabjA0</Job_Src_Id_Material>
<Job_Dest_User_Nb>11</Job_Dest_User_Nb>
< Job_Dest_Clip_Nb >112</ Job_Dest_Clip_Nb >
< Job_Dest_Cam >A</ Job_Dest_Cam >
<Job_Src_App_Data>Job generated by XGateway</Job_Src_App_Data>
</EVS_XFile_Job>
</EVS_XFile_Job_List>
See XFile XML jobs documentation for complete description of XML files.
XML Default Parameters
It can occur that some XML parameters are not defined by the source application. In this
case, XML Default Parameters mentioned in the XML Tab are taken into account for the
missing XML parameters.
XML Backup Output Parameters
The File Format drop-down list allows the user to select the default file format.
The following formats are available:
• EVS MXF
• MXF OP1a (SD IMX only)
• Quick Time Movie
• Quick Time Reference
• Avid Ingest Device
• CleanEdit Reference
• Avid MXF OPAtom
• MXF OP1a (Std SMPTE)
When the Generate EVS XML Metadata check-box is selected, an XML file with the
metadata is generated. This file is created at the same time as the backup file for all
media file formats.
