XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
31
AutoImport
MXF and MOV Files
When working with .mxf or .mov files, not associated with a separate XML file, select the
AutoImport box. This parameter allows the extraction of metadata information and the
creation of XML files.
When the import of files into the scan folder is done manually, XML files which could have
been created must not be imported.
Video Files with XML files
When working with file formats associated with a separate XML file, do not select the
AutoImport box.
When the import of files into the scan folder is done manually, XML files must not be
copied before the video files, otherwise the job will start before the video file is present
and the job will be set as Failed in the Job Status pane. In this case, the folder will
automatically be rescanned and a second job line will appear in the Job Status pane with
the Successful status.
Parameters for Restore
Restore Mode
Two Restore Modes are available:
• Restore: keeps original IDs. In case the ID already exists, the job will fail.
• Copy: generates new UmID
Destination Server
Select the server name where you want to restore the files.
Location
The Location area indicates in which locations the files will be restored.
