Issue 2.19.A
XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
20
Three conditions are required to validate the Archive status:
1.
Before the Autobackup session, place a checkmark in the following box:
2.
Set the ‘DEFAULT XFILE’ parameter in the Setup menu of your EVS video server.
(See Multicam documentation for complete information).
The label appears on the line of the EVS video
server if the
‘DEFAULT XFILE’ has been correctly defined.
3.
Activate the AUTOBACKUP by clicking the button in the XFile main
window.
Note
The Default XFile setting allows the user to initiate the backup of a clip from
the EVS video server via the >ARCHIVE command (see Multicam
documentation for details).
The Archive Flag also initiates the backup of a clip as requested by the
>ARCHIVE command even if the Default XFile is not set, but the Archive
status on the EVS video server is not updated.
Time Range
The autobackup session can be defined for a specific duration.
Select the check-box to activate the time range filter and click one of the Time Range
Selection button to access this window:
