XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
15
3.3 Session Configuration
Once the XFile application is started, the users can define the session configuration by
selecting Configuration > Config Session from the main menu.
The session configuration window is divided into 8 tabs:
Tab 1 - Autobackup
Tab 2 – MXF Metadata
Tab 3 – Manual Backup
Tab 4 – Scan Folder
Tab 5 – Grab
Tab 6 – Export
Tab 7 – XML
Tab 8 – User Parameters
3.3.1 Tab 1 - Autobackup
XFile allows the users to define three different selections of servers, cameras and pages
from which backing clips up in Autobackup mode.
For the three selections, the output files can be saved with different formats, and to
different paths.
In addition, each selection can be saved to a second output as soon as 2 disks are
available.
The Autobackup tab contains 4 sub-tabs highlighted in the next screenshot:
• Primary Selection (1)
• Secondary Selection (1)
• Third Selection (1)
• Autobackup Validation (2), displaying the current selection of Autobackup
Each of the three Selection tabs includes several areas:
• Selection list (3)
• Selection shortcuts (4)
• Additional autobackup criteria (5)
• Output parameters (6)
