Issue 2.19.A
XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
174
5.3.3 Fields in the Configuration Window
The following table describes the various fields in the Configuration window:
Field Description
Drop-down list box in which the user selects the
separator to be used in the TXT and CSV files to
separate the metadata values of a clip.
Left list box
List of all selectable clip metadata.
Right list box
Selection of clip metadata that will be exported to an
output file.
Button to remove from the selection
the clip
metadata selected in the right table.
Button to add to the selection
the clip metadata
selected in the left table.
Button to import
a configuration file. The
configuration file that will automatically be imported
needs to be located in the folder C:\
Program
Files\
EVS Broadcast
Equipment\XFile and be called
XFile_ClipInfo_Exporter_Config_Fi
le.xml.
