Issue 2.19.A
XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
8
Video Standard (PAL/NTSC)
This parameter specifies the video standard. NTSC format is also applicable for HD
formats.
Database Size (32000 clips)
This parameter specifies the maximum number of clips saved to the LSM database.
VarID Uniqueness (Global / Local)
This parameter specifies at which level the VarID is unique:
• Global: the VarID is unique at the XNet network level
• Local: the VarID is unique at the EVS video server level.
VarID Length (8 char / 32 char)
This parameter specifies the VarID length:
• Fixed length of 8 bytes
• Variable length of 32 bytes
VarID Format (ASCII / Binary)
This parameter specifies the VarID format:
• ASCII
• Binary
Note
The VarID will only be displayed in the XFile application if this has the ASCII
format. Otherwise, the string <Unicode> will be displayed in the VarID column
of the XFile lists in the various XFile modes.
3.1.2 Transfer Mode
Three different operational modes are available: XNet only, GBE only and a combined
mode GBE + XNet.
Note
An SDTI connection is still required in all modes to access the data.
XNet Only
All the transfers are processed through the XNet.
