Issue 2.19.A
XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
154
4.10.5 Storage Tab
The Storage tab allows the user to define settings on how and where the backup file will
be stored.
These settings will have priority on the default settings defined in the Storage tab of the
XStream Configuration window.
Setting Name Description
Number of disks Specifies the number of disks assigned to the channels
to backup. It is highly recommended to balance the load
over several disks to ensure good performances in data
transfers.
Path Channel Specifies the path where the backup files need to be
saved for each channel. Depending on the number of
disks selected, the path channel will automatically be
updated for all path channels once you have entered the
names for the first one, two or three path channels.
