XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
137
4.8 Contextual Menu in the Scheduler
Different contextual menus are available from the time grid depending on where the right-
click is performed:
4.8.1 Contextual Menu from the XNet Label
Command Description
Auto-Hide
Disconnected XTs
Select this option to hide or display the disconnected EVS
video servers.
Collapse not
Available Inputs
Select this option to hide the time grid for the cameras not
available on the XNet network.
Collapse All Inputs
Select this option to hide the time grid for all cameras of the
XNet network.
Expand Available
Inputs
Select this option to show the time grid for
the cameras
available on the XNet network.
Expand All Inputs
Select this option to show the time grid for all cameras of the
XNet network.
If the Auto-hide Disconnected XTs option
is active, the
cameras on the disconnected EVS video servers will not be
displayed.
