XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
125
Number of Disks
Specifies the number of disks assigned to the channels to backup.
Note
In order to ensure good performances in data transfers we highly recommend
balancing the load onto several disks.
Path Channels
Those fields specify the paths where the files will be saved for each channel.
4.6.2 Jobs Tab
The settings specified in the Jobs tab are applicable to the Scheduler and QuickStart
modes, except the Default Job Duration option which is only relevant in the Scheduler
mode.
These are the default settings for the QuickStart mode. Before launching a QuickStart
job, you can define other settings in the Output tab of the QuickStart Setup window. Refer
to section 4.10.3 ‘Setup in QuickStart Mode’ on page 152. They will have priority on these
default settings, provided that the option Keep Outputs’ Configuration while Creating a
Job has been selected in the Jobs tab.
